Orbical LED Large Harness

The Lumisphere® Orbical LED range is a plug in LED light module which uses a number of SMD LEDS to create a 360 light source with similar light appearance to a traditional light bulb. The LED light unit is designed as a simple retro fit LED for any Lumisphere® existing X12 installation.

Product Details
Supply Low Voltage, High Output 12v AC/DC
Average Lamp Life 50,000hrs Life Expectancy
IP Rating IP68 Rated
Conformity UL Listed
Warranty Three Year Warranty
Built to your specification


Product Options
Light Sources Orbical 8 Module – 1 Watt (Lumen Output 60),
Orbical 24 Module – 1.2 Watt (Lumen Output 90),
Orbical 48 Module – 2 Watt (Lumen Output 130),
Globes G type or A type (IK10 Rated)
LED Colours Warm White (3000k), Cool White (5000k), Red, Blue, Green, Amber, Purple
Globe Colours Clear, Frosted, White (G Type only), Red, Green, Blue, Purple and Pink
Lampholder/Cable Colour Black or White

Data Sheets available upon request


Lumisphere’s Large and Small Harness festoon systems can be purchased in component form, if required, for self-assembly. In instances where irregular distances between light units are required, or on-site assembly of materials is required, e.g. signage, ceilings, fascias etc, this may preferable. On-site self-assembly tools can also be purchased – please ask the team for more details.

Optional Lampholder and Globe Accessories
